RKS.161.14.0544 Slewing Bearings

RKS.161.14.0544 Crossed Roller Slewing Bearing with External Gear - High-Precision Industrial Rotation Solution

Luoyang Heng Guan Bearing Technology presents the RKS.161.14.0544 Slewing Bearings, a single-row crossed cylindrical roller slewing bearing with external gear precision-engineered for demanding industrial applications. With over 30 years of slewing bearing expertise, our factory delivers this 544 mm mean raceway diameter bearing featuring 640.8 mm outside diameter, 474 mm bore, and 56 mm height. Rated at 784 kN static axial load capacity (C0) and 194 kN dynamic capacity (C), this 44 kg unit incorporates module 6 with 105 teeth external gear. ISO9001 certified and RoHS compliant, our RKS.161.14.0544 offers direct interchange with SKF RKS.161.14.0544, INA XSA14 0544N, and Rothe Erde 161 series. Production capabilities span 50-10000mm diameters across P0-P4 precision grades.

Technical Specifications of 161.14.0544 Slewing Ring Bearing

Why Choose RKS 161 14 0544 Crossed Roller Slewing Bearing?

The crossed roller design of the RKS.161.14.0544 slewing ring bearing delivers exceptional rigidity and load capacity in a compact 56 mm height profile. Unlike conventional ball bearings, the 14 mm crossed cylindrical rollers provide 90° alternating contact angles, enabling simultaneous handling of axial forces, radial loads, and tilting moments without requiring supplementary support structures.

Our manufacturing process employs CNC vertical lathes and CNC quenching machines to achieve HRC 55-62 raceway hardness through precision induction hardening. The C45E/42CrMo4 ring material undergoes strict heat treatment, ensuring core toughness while maintaining surface wear resistance. This combination extends service life in high-cycle applications.

The external gear features module 6 with 105 teeth machined on our CNC gear shapers to 20° pressure angle standards. With −0.6 addendum modification, the gear tolerates 16 kN normal tooth forces and up to 54 kN maximum load for 3 million cycles. This makes the bearing ideal for continuous rotary motion applications requiring direct drive solutions.

Integral NBR seals protect against contamination from −40 to +110 °C, while four M10×1 grease fittings facilitate NLGI 2 lithium EP lubrication maintenance. Running accuracy remains within radial 0.2 mm and axial 0.3 mm tolerances, meeting precision rotary table requirements.

Cross Reference and Interchange Compatibility

The crossed roller slewing bearing external gear 640.8mm design offers direct dimensional interchange with multiple bearing manufacturers:

· SKF: RKS.161.14.0544 (original specification)

· INA: XSA14 0544N (external gear) / XSU14 0544 (no gear)

· Rothe Erde: 161 series crossed roller type

· Heng Guan Bearing: HGB-161.14.0544 (factory direct equivalent)

Note that INA XSA140544N specifications list 640.3 mm outside diameter versus SKF's 640.8 mm—a 0.5 mm tolerance within industry standards. Both versions maintain identical bolt patterns (Ø585/M12×28 outer, Ø498/Ø14×32 inner) ensuring mounting compatibility for aftermarket replacement applications.

You can upgrade to four-point ball bearing configurations like RKS.061.20.0544 for applications prioritizing cost over load capacity, or specify our triple-row roller designs when exceeding 784 kN static load requirements.

Industrial Applications of Cross Roller Swing Bearing External Teeth 0544

Robot Waist and Joint Assemblies

The robot waist RKS.161.14.0544 Slewing Bearings provide compact rotation for industrial manipulators. The 544 mm raceway diameter accommodates cable and pneumatic routing through the hollow bore, while the external gear enables precise servo motor indexing. Low starting torque and ≤0.2 mm radial runout ensure accurate end-effector positioning.

Welding Positioner Systems

Welding positioner crossed roller slewing bearing 0544 installations benefit from the bearing's 784 kN static load capacity when supporting heavy weldments. The crossed roller arrangement resists tilting moments during off-center loading, maintaining workpiece stability during automated welding cycles. NBR seals protect against welding spume contamination.

CNC Rotary Tables and Indexers

For CNC rotary table bearing XSA14 0544N applications, the precision-ground raceways deliver ≤0.3 mm axial runout critical for multi-axis machining accuracy. The 105-tooth external gear pairs with stepper or servo drives for repeatable angular positioning. Our P5 precision grade option (available on request) further reduces motion error for grinding and inspection equipment.

Mini Excavator Swing Mechanisms

Mini excavator swing bearing crossed roller 0544 units handle combined radial boom loads and axial slew forces within the compact 56 mm height envelope. The through-hardened 100Cr6 rollers resist shock loading during digging cycles, while permissible 2 m/s brief speeds accommodate rapid cabin rotation.

Solar Tracking Systems

In solar tracker slew bearing external gear 0544 installations, the bearing's continuous 1.5 m/s speed rating supports single and dual-axis tracking. The external gear integrates with worm or helical drives for high-reduction self-locking. Temperature-stable NBR seals maintain lubrication integrity across −40 to +110 °C ambient conditions common in desert deployments.

Lifting and Material Handling

Lifting equipment cross roller swing bearing 161.14.0544 configurations leverage the 194 kN dynamic load rating for crane pedestals and aerial platform turrets. The 28 M12 outer ring bolts distribute mounting stresses across base structures, while 32 inner ring connections secure rotating superstructures without oversized bolt patterns.

Manufacturing Excellence and Quality Control

Heng Guan Bearing's production facility houses CNC vertical lathes capable of machining the 640.8 mm outer diameter with ±0.05 mm tolerance. Our CNC quenching machines apply controlled induction heating to achieve uniform HRC 55-62 hardness across the raceway width, preventing soft spots that lead to premature fatigue.

Gear manufacturing employs large gear hobbing machines and CNC gear shapers to produce the module 6 profile with ISO 1328 Grade 7 accuracy. Coordinate measuring machines verify tooth spacing and profile angles, ensuring clearance consistency for smooth meshing under the 16 kN nominal tooth force.

Every RKS.161.14.0544 slewing bearing undergoes dimensional inspection, raceway hardness testing, and gear runout measurement before packaging. We maintain full material traceability per EN 10204 3.1 standards, with test certificates documenting chemical composition and heat treatment parameters for each production batch.

Our ISO9001 quality management system governs all processes from raw material procurement through final inspection. RoHS compliance ensures the bearing contains no restricted substances for European and North American markets.

Delivery and Service Support

Standard RKS.161.14.0544 in stock configurations ship within 3-7 days from our Luoyang warehouse. Non-standard requests—such as alternative seal materials, special lubrication, or precision grade upgrades—typically require 25-30 days for custom manufacturing.

We offer factory direct pricing with minimum order quantity (MOQ) of one piece, making prototype and replacement orders economically viable. Bulk purchasers benefit from volume discounts and scheduled delivery programs supporting just-in-time inventory management.

Our engineering team provides technical consultation covering bearing selection, mounting procedures, and lubrication specifications. We supply CAD drawings in DXF and STEP formats for design integration, plus datasheet PDFs documenting load ratings and boundary dimensions.

For legacy equipment, our old product mapping service reverse-engineers worn bearings to produce dimensionally accurate replacements—even when original drawings are unavailable. Personalized non-standard customization accommodates modified bolt patterns, integrated flanges, or special coatings for corrosive environments.

Installation guidance includes proper bolt torque sequences (cross-pattern tightening to 85 Nm for M12), soft zone orientation recommendations, and initial lubrication fill procedures. We support OEM partnerships with private labeling and co-developed bearing solutions for specialized excavator.

FAQ

Q: What is RKS.161.14.0544?

A: RKS.161.14.0544 is a single-row crossed cylindrical roller slewing bearing with external gear, manufactured to SKF RKS.161 standards. It features 544 mm mean raceway diameter, 474 mm bore, 640.8 mm outside diameter, and 56 mm height, weighing 44 kg.

Q: What are the dimensions of RKS.161.14.0544?

A: Bore 474 mm, outside diameter 640.8 mm, total height 56 mm. The external gear has 630 mm pitch circle diameter, module 6, 105 teeth. Complete assembly weighs 44 kg with bolt circles at Ø585 mm (outer) and Ø498 mm (inner).

Q: Is RKS.161.14.0544 equivalent to INA XSA14 0544N?

A: Yes. INA XSA14 0544N (external gear) and XSU14 0544 (no gear) are dimensionally interchangeable. The outside diameter varies by 0.5 mm (640.8 vs 640.3 mm) within tolerance, with identical bore, height, and bolt patterns for direct replacement.

Q: What is the load capacity of RKS.161.14.0544?

A: Dynamic axial load rating C = 194 kN, static axial load rating C0 = 784 kN. The external gear permits 16 kN normal tooth forces and 54 kN maximum load for 3 million cycles on normalized gear material.

Q: Is RKS.161.14.0544 in stock?

A: Stock models ship in 3-7 days. Non-stock standard configurations require 25-30 days production time. Contact mia@hgb-bearing.com for current availability, factory-direct pricing, and technical datasheets for your specific application.
