23 0411 01 slewing bearing

Series Number: 23 Series (Light Series)
Bearing Type: Single Row Four-Point Contact Ball Slewing Ring
Cross-Section Shape: L-Shaped Profile, Thin Section
Tooth Type: Without Gear
Rolling Element: Steel Ball, with Isolating Cage
Accuracy Class: Normal Clearance (Class I)
Material: XC45 (Standard) / 42CrMo4 (Optional) / 50Mn
Cage: Nylon PA66 Space Retainer
Seal: NBR Lip Seals Both Sides
Lubrication: Grease Lubrication, with Oil Filler Hole
Raceway Hardness: HRC 55 ~ 60
Operating Temperature: -20℃ ~ +40℃ (Standard)
Number of Models: 7 Standard Models
OD Coverage: 518 mm ~ 1198 mm
Weight Range: 23 kg ~ 67 kg
Uniform Height: H = 56 for all series mm (thin-wall characteristics)

Product Description

23 0411 01 Slewing Bearing – Flanged Thin-Section Solution for Space-Constrained Rotary Applications

The 23 0411 01 Slewing Bearing is a single-row four-point contact ball slewing ring from the Rollix 23 Series (Light Series), specifically engineered for applications demanding lightweight design and flange-type mounting. With an outer diameter of 518 mm, inner diameter of 304 mm, and uniform height of 56 mm, this bearing weighs only 23 kg. Its L-shaped flanged profile enables direct mounting without additional support structures, making the product ideal for small cranes, aerial work platforms, solar trackers, and radar antenna mounts where installation space is limited. The bearing features NBR double-lip seals, grease lubrication with refill ports, and raceway hardness of HRC 55-60 for reliable performance in temperatures ranging from -20℃ to +80℃.

What Makes the 23 Series Unique Among Slewing Bearings?

No other gearless slewing bearing series has integrated flange mounting surfaces like the 23 Series. The 23 Series' L-shaped flanged profile facilitates installation and assembly, unlike the rectangular cross-section 03 Series or solid-section 33 Series. This design is similar to INA VLU200xxxx and RKS.23 or Kaydon RK6.

All seven 23 Series variants are 56 mm tall, making them interchangeable in equipment with conventional mounting specifications. Instead of specialized adapter plates, the outer ring's integral flange offers a robust bolting contact.

23 0411 01 slewing bearing

Technical Specifications

Attribute	Specification
Brand	Rollix (Defontaine Group)
Series	23 Series (Light Series)
Bearing Type	Single Row Four-Point Contact Ball
Cross-Section	L-Shaped Flanged Thin Section
Gear Type	Without Gear (Gearless)
Rolling Elements	Steel Balls with PA66 Nylon Space Retainer
Accuracy Grade	Normal Clearance (Class I)
Material	XC45 (Standard) / 42CrMo4 / 50Mn
Sealing	NBR Lip Seals (Double-Sided)
Lubrication	Grease with Refill Holes
Raceway Hardness	HRC 55–60
Operating Temperature	-20℃ to +80℃
OD Range	518 mm – 1198 mm
Weight Range	23 kg – 67 kg

23 Series Complete Model Range

Model	OD (mm)	ID (mm)	H (mm)	Weight (kg)	PCD La (mm)	PCD Li (mm)
23 0411 01	518	304	56	23	490	332
23 0541 01	648	434	56	34	620	462
23 0641 01	748	534	56	40	720	562
23 0741 01	848	634	56	46	820	662
23 0841 01	948	734	56	52	920	762
23 0941 01	1048	834	56	58	1020	862
23 1091 01	1198	984	56	67	1170	1012

Note: La = outer ring bolt circle diameter; Li = inner ring bolt circle diameter. Consult factory drawings for bolt specifications.

Key Engineering Advantages

Lightweight Thin-Wall Construction: The 23 Series achieves 30-40% weight reduction compared to rectangular-section 03 Series bearings of equivalent outer diameter, directly lowering inertia and energy consumption in rotary systems.

Integrated Flange Mounting: The outer ring's machined flange eliminates custom mounting brackets. Your installation team can bolt the 23 0411 01 slewing bearing directly to the supporting structure, reducing assembly time by up to 50%.

Four-Point Contact Load Distribution: Unlike crossed-roller bearings that handle primarily radial loads, this bearing's ball-race geometry simultaneously manages axial forces, radial loads, and tilting moments within a single compact unit.

Pre-Sealed and Pre-Lubricated: Dual NBR lip seals prevent contamination ingress in dusty or humid environments. The pre-filled grease and strategically located refill ports enable maintenance without disassembly.

23 0411 01 slewing bearing

Application-Specific Recommendations

Application	Recommended Models	Technical Rationale
Flanged slewing ring for small crane / slewing ring for jib crane flanged	23 0411 ~ 23 0641	Thin-wall design suits compact truck-mounted cranes with limited swing radius
Slewing bearing for aerial work platform	23 0411 ~ 23 0641	23 kg starting weight reduces platform counterweight requirements
Flanged slewing ring for solar tracker	23 0541 ~ 23 0841	Flange mounting simplifies seasonal tracker adjustments and field installation
Slewing bearing for radar antenna mount / slewing ring for telescope mount	23 0411 ~ 23 0741	Normal clearance grade meets positioning accuracy for communication systems
L-shaped slewing ring for turntable / flanged turntable bearing for robot	23 0411 ~ 23 0641	Standardized 56 mm height enables modular machine design
Packaging Excavator Turntables	23 0411 ~ 23 0541	Compact footprint for conveyor integration
Medical Equipment Platforms	23 0411	Lowest noise profile in the series

23 Series vs. Alternative Designs

Comparison	23 Series (Light)	03 Series (Standard)
Cross-Section	L-shaped flanged	Rectangular
Wall Thickness	Thin section	Standard
Height	Uniform 56 mm	25–100 mm (model-dependent)
Weight	Lighter (same OD)	Heavier
Mounting	Flange-bolted	Direct bolt-through
Typical Use	Space-limited applications	General-purpose excavator

Certification

23 0411 01 slewing bearing

FAQ

Q: Can I replace a 23 0411 01 bearing with an INA VLU equivalent?

A: Yes, the 23 Series is dimensionally compatible with INA VLU200xxx series. Verify bolt hole patterns in your specific application before substitution.

Q: What is the recommended maintenance interval?

A: Re-lubricate every 500 operating hours or annually. Use lithium-based NLGI Grade 2 grease through the provided filling ports.

Q: Does this bearing support external gear-driven rotation?

A: No. No. The 23 Series is gearless. If you require integrated gearing, consider the 21 Series (external teeth) or 22 Series (internal teeth).

Q: What delivery time should I expect?

A: In-stock products ship within 7-15 days. Custom configurations take 4-6 weeks depending on intricacy.

Contact Us

Need dimensional verification or load calculations for your application with 23 0411 01 slewing bearing? Request technical datasheets or discuss sample availability at Contact Us Need dimensional verification or load calculations for your application? Our engineering team provides mounting guidance, CAD integration support, and material certificates. Request technical datasheets or discuss sample availability at mia@hgb-bearing.com to ensure proper bearing selection for your project requirements.">mia@hgb-bearing.com to ensure proper bearing selection for your project requirements.
