RKS.23.0411 Slewing Bearings

RKS.23.0411 Slewing Bearings — SKF RKS.23 Light Series Ungeared Turntable Bearing | Factory Direct Supply

Luoyang Heng Guan Bearing Technology Co., Ltd. is your trusted source for the RKS.23.0411 Slewing Bearings — the smallest model in the SKF RKS.23 light series, featuring a 518 mm OD, 304 mm bore, and 56 mm height, weighing just 23.5 kg. Backed by over 30 years of precision manufacturing experience, ISO 9001 certification, and a dedicated team of 50+ engineers in Luoyang, China, we manufacture slewing bearings from 50 to 10,000 mm in P0, P6, P5, and P4 precision grades. Products are exported to 50+ countries with factory-direct pricing and 3–7 day stock delivery.

Full Technical Specifications of the RKS.23 0411 Four Point Contact Ball Slewing Ring

Key Product Advantages of This Gearless Four Point Contact Ball Slewing Bearing

Lightest in the RKS.23 series. At just 23.5 kg, RKS.23.0411 Slewing Bearings is air-freight friendly and easy to handle on-site. This keeps your logistics costs low and delivery timelines short.

Direct-drive ready design. Both the outer and inner rings feature 18 mm through holes — no M12 threads, unlike the RKS.21/22 geared variants. This makes the bearing ideal for external motor or direct-drive setups.

Outstanding load capacity for its size. With a dynamic rating of C = 169 kN and static rating of C0 = 284 kN, this single-row bearing handles combined axial, radial, and tilting moment loads with confidence.

Induction-hardened raceways. The raceway surface reaches HRC 55–62, while the core remains tough enough to absorb shock loads. This gives you excellent fatigue resistance and a long service life.

Reliable sealing and lubrication. The NBR one-piece seal operates from –40 °C to +110 °C. Four grease nipples on the inner ring make re-lubrication straightforward, even in the field.

Cross Reference & Interchange — RKS.23.0411 Equivalent Bearings

If you're sourcing a replacement or alternative, this bearing is a confirmed drop-in equivalent for several leading brands:

Looking for a VLU200414 equivalent? You're in the right place. Our RKS.230411 is dimensionally and functionally interchangeable, and ships from stock in days — compared to typical 68-day European lead times at a fraction of the retail price.

Typical Applications of the RKS.23 Light Series Ungeared Turntable Bearing

This compact, gearless slewing ring fits a wide range of industries:

· Truck cranes & mobile cranes — handles combined loads with shock resistance in heavy lifting environments

· Robot palletizers & logistics automation — smooth, precise rotation for repetitive high-cycle operations

· Filling & packaging excavator — low-noise, compact footprint for high-speed production lines

· Medical & precision equipment — quiet running, high accuracy, and vibration-free rotation

· Solar trackers — reliable low-speed rotation with minimal maintenance requirements

The 518×304×56 mm footprint and 23.5 kg weight make it particularly attractive wherever space and weight are a concern.

Why Choose Heng Guan Bearing for Your RKS.23.0411 Slewing Bearings Order?

Factory-direct pricing. You buy directly from the manufacturer — no middlemen, no markup. This is especially significant compared to European distributor pricing.

Fast delivery. Stock units ship within 3–7 days. Non-stock standard models are ready in 25–30 days. Air freight is available for single units.

Minimum order of just 1 piece. You don't need to commit to large volumes to get started. MOQ = 1 pc.

Full technical support. Our engineers are available to assist with selection, installation guidance, and re-lubrication planning. We also accept OEM/ODM requests and non-standard customization.

Strict quality control. Every bearing goes through coordinate measuring machine inspection, vibration testing, and full material traceability from raw steel to finished product.

Packaging & Shipping

Each bearing is wrapped in anti-rust film, packed in a wooden case, and clearly labeled with model, dimensions, and batch number. The 23.5 kg unit qualifies for standard air freight — ideal for urgent single-piece orders. Sea freight and express courier are both available for bulk and single orders respectively.

FAQ

Q1: What is RKS.23.0411?

A: It is the smallest model in the SKF RKS.23 light series — a single-row four point contact ball slewing bearing without gear. Key dimensions: 518 mm OD, 304 mm bore, 56 mm height, 411 mm mean raceway diameter, 23.5 kg weight.

Q2: What are the exact dimensions and bolt hole details?

A: Outside diameter 518 mm, bore 304 mm, height 56 mm. Outer bolt circle: 490 mm, 8 × 18 mm through holes. Inner bolt circle: 332 mm, 12 × 18 mm through holes.

Q3: Is RKS.23.0411 equivalent to INA VLU200414?

A: Yes. INA VLU200414 and its variant VLU200414-ZT are confirmed Schaeffler interchanges. Kaydon RK6-16P1Z, Rollix 23-0411-01, Rothe Erde 230.20.0400, and TGB 90-200411 are also drop-in equivalents.

Q4: What is the load capacity?

A: Dynamic axial load rating C = 169 kN; static axial load rating C0 = 284 kN. The four point contact design supports combined axial, radial, and tilting moment loads simultaneously.

Q5: Is this bearing in stock and available for fast delivery?

A: Yes. Stock units ship in 3–7 days, with air freight available for the 23.5 kg unit. Non-stock standard models ship in 25–30 days. MOQ is 1 piece.

Q6: What causes slewing bearing failure and how do I maintain this bearing?

A: The most common causes are inadequate lubrication and contamination. Re-lubricate every 100 operating hours using NLGI 2 lithium EP grease through the 4 × AM8×1 nipples. Inspect the NBR seal regularly for wear or damage.

Contact Us

Ready to order or need a custom quote for the RKS.23.0411 Slewing Bearings? Email us at mia@hgb-bearing.com — we respond within 24 hours.
